DH 314

Descriptions:

This lever/pad door handle compliments the Claymore series of window handles, hinges and Zinc framed letterplates. Designed for applications where a short backplate is required, the fixings are sited below the handle grip. The door handle is designed to incorporate two internal spring cassettes if required, to ensure a positive and precise operation.

Features:

  • Lever/pad variants: non-handed
  • Suitable for 92 PZ centres.
  • 30mm backplate width; blank backplate option available to special order
  • Spring cassette option
  • Supplied with 1x8mm spindle and screw pack included as standard for 70mm door thickness
  • Die-cast Zinc Alloy
  • 2 year surface finish guarantee thanks to durable PVD coating
  • Colour co-ordinated screw heads
  • Packed as 1 pair per box, 20 boxes per carton
